| SPECIFICATION | WINNOWING FAN : BKUPFAN1 |
|---|---|
| Dimensions | L: 865mm, W: 690mm, H: 1660mm |
| Power Unit | 0.5 HP Single Phase Motor |
| Motor Speed | 1500 RPM |
| Safety | Comes with Safety Guard |
| SPECIFICATION | GOKUL-7 PLUS (Tractor – PTO Operated) |
|---|---|
| Dimensions | L: 3048mm, W: 1650mm, H: 1575mm |
| Power Unit | Tractor PTO, 35 HP and above |
| Number of Blades | 4 Blades (3 Rotating, 1 Fixed) |
| Capacity | 1000 – 5000 kg/hr |
| SPECIFICATION | POWER PACK |
|---|---|
| Dimensions | L: 100mm, W: 450mm, H: 825mm |
| Power Unit | 3 H.P. Motor (2800 RPM) |
| Number of Blades | 4 Blades |
| Capacity | 400 – 600 kg/hr |
| SPECIFICATION | GOKUL-12 |
|---|---|
| Dimensions | L: 1448mm, W: 1270mm, H: 1389mm |
| Power Unit | Single Phase 1.0 HP Motor (1440 RPM) |
| Number of Blades | 3 Blades (2 Rotating, 1 Fixed) |
| Capacity | 250 – 350 kg/hr |
| SPECIFICATION | GOKUL-15 PLUS |
|---|---|
| Dimensions | L: 1650mm, W: 965mm, H: 1168mm |
| Power Unit | Single Phase 3.0 HP Motor (1440 RPM) |
| Number of Blades | 3 Straight Blades |
| Capacity | 1000 – 1500 kg/hr |
| SPECIFICATION | GOKUL-15 |
|---|---|
| Dimensions | L: 1650mm, W: 965mm, H: 1168mm |
| Power Unit | Single Phase 3.0 HP Motor (1440 RPM) |
| Number of Blades | 3 Straight Blades |
| Capacity | 1000 – 1500 kg/hr |
| SPECIFICATION | GOKUL-1 PLUS |
|---|---|
| Dimensions | L: 1625mm, W: 812mm, H: 965mm |
| Power Unit | Single Phase, 2.0 HP Electrical Motor, 1440 RPM, 50 Hz, 220V |
| Number of Blades | 3 Blades (2 Rotating, 1 Fixed) |
| Capacity | 800 kg/hr |
| SPECIFICATION | GOKUL-9 PLUS | GOKUL-10 PLUS |
|---|---|---|
| Dimensions | L: 1780mm, W: 1092mm, H: 1270mm | L: 1780mm, W: 1194mm, H: 1270mm |
| Power Unit | Single Phase, 2.0 HP Electrical Motor, 1440 RPM, 50 Hz, 220V | Single Phase, 3.0 HP Electrical Motor, 1440 RPM, 50 Hz, 220V |
| Number of Blades | 3 Blades (2 Rotating, 1 Fixed) | 3 Blades (2 Rotating, 1 Fixed) |
| Capacity | 1000 kg/hr | 1500 kg/hr |
